Are you an FPV fanatic desperately seeking a flight controller that integrates the trifecta of power, precision, and endless customization? Does your quest for the ultimate "digital whoop" experience keep you up at night, flipping through forum after forum? Well, you can finally rest easy, mate. The SuperX HD ELRS 1-2S AIO Flight Controller is your silver bullet!
The Agony of Average Stops Here!
| Flight controller SuperX HD ELRS |
Betaflight 4.4.2 firmware ready
Firmware target: CRAZYBEEF4DX MCU:STM32F411CEU6 (100MHz, 512K FLASH) Sensor: BMI270 or ICM42688P (SPI connection) Power supply: 1-2S Lipo Lihv battery input (DC 2.8V~8.7V), only support 1s input for this drone Built-in 12A(each) Blheli_S 4in1 ESC Dshot300 read Built-in UART elrs receiver , elrs v3.0 ready, support WIFI and pass-through firmware update Bluejay ESC Firmware ready Built-in 5V 1.5A(Max) BEC Built-in voltage detectionBuilt-in currents meter No betaflight analog osd chip Antenna:enamel copper wire |
| Onboard 4in1 ESC |
Power supply: 1-2S LiPo/LiPo HV
Current: 12A continuous peak 15A (3 seconds) Support ESC-Configurator and BLHELI_S Suite configurator Factory firmware: Z-H-30 - Bluejay, 0.19, 48kHz Default protocol: DSHOT300 |
| Onboard UART ExpressLRS 2.4GHz Receiver |
RF Frequency: 2.4GHz
Antenna: enameled copper wire 31mm length Telemetry output Power: <12dBm Receiver protocol: CRSF Default firmware version: ExpressLRS V3.0.1 The same hardware with Happymodel EP1 receiver Could update firmware via ExpressLRS configurator or WIFI or Betaflight pass-through |
Before you dive in, note that you should possess the soldering skills of a Zen master. Those tiny pads require a steady hand and a focused mind. And just to be crystal clear—any damage due to soldering mishaps is on you, buddy.
Time to Elevate Your Game
This flight controller is like the Swiss Army knife of the FPV world. You get reliability, customization, and performance, all rolled into one. Why settle for less when you can pilot the best?
So, click that "Add to Cart" button now and embrace the future of FPV flying. Trust us, this is the upgrade you didn't know you needed. But you'll wonder how you ever flew without it.
Q: Can I update the firmware easily? A: Absolutely! The ELRS receiver supports updates via ExpressLRS configurator, WiFi, or Betaflight pass-through.
Q: Is this compatible with my Happymodel EP1 receiver? A: Yes, it's the same hardware!
Q: What about warranty? A: Check our Warranty Policies page for the nitty-gritty, but remember: soldering issues are not covered.
