Description
LED indicator status description:
1. The left power light-always on: normal power
2. The middle GPS light flashes: searching for GPS signals
3. The middle GPS light is always on: GPS signal is normal
4. The GSM light on the right flickers: searching for GSM signals
5. GSM on the right side is always on: the GSM signal is normal and the card has been read
Product parameter specifications:
1. Dimensions: 63mm x 46mm x 17mm
2. Weight: 40 grams
3. Network: GSM/GPRS
4. Network frequency band: 850/900/1800/1900Mhz
5. Chip: UBLOX
6. GPS sensitivity: -159dBm
7. GPS accuracy: 5 meters
8. Battery: 3.7V 180 mAh
Functional advantages:
1. Add shift alarm and alarm in electronic fence area
2. Add smart power saving mode
3. Add oil and power off, ACC status notification function, low power/power off alarm
4. Blind zone supplementary transmission function, when there is no mobile phone signal, the data is saved in GPS, and will be supplemented when there is a signal
5. AGPS function, fast satellite positioning
Basic configuration: host, power cord, manual, double-sided stickers
Specification:
| Package Weight |
| One Package Weight |
0.05kgs / 0.12lb |
| One Package Size |
10cm * 7cm * 3cm / 3.94inch * 2.76inch * 1.18inch |
| Carton Weight |
27.00kgs / 59.52lb |
| Carton Size |
50cm * 50cm * 54cm / 19.69inch * 19.69inch * 21.26inch |
| Loading Container |
20GP: 197 cartons * 500 pcs = 98500 pcs
40HQ: 458 cartons * 500 pcs = 229000 pcs
|
|
