Wide measuring range : it can detect temperature range from -40 to +80 °C, soil moisture range from 0 to 100%
Industrial design : -40 ~ 85℃ operating temperature and IP66 rating, suitable for indoor, outdoor, and harsh environments such as high UV exposure, heavy rain, dusty conditions, etc.
Bluetooth configuration in 1 min : scan the QR code on the device and finish the configuration work in just a few clicks
Easily get data, no clunky software interfaces : smooth data flow to cloud servers or other IoT data management platforms
Visualize data and monitor with SenseCAP Mate APP : you can set threshold value (just focus on the data you need to take action for), time intervals (improve the battery efficiency), and set alarms if data is out of the safe range.
LoRaWAN wireless transmission : ultra-low power consumption to support Max.10 years of battery life and ultra-wide-transmission range of 2km in urban scenes and 10km in line of sight scenes
Supported by Worldwide LoRaWAN Networks : can be used with different types of LoRaWAN gateways and compatible with multiple LoRaWAN Network Servers (Helium, TTN) to enable our sensor quickly join your current LoRaWAN networks
Soil moisture and temperature are two important environmental parameters in planting while soil EC (electrical conductivity) is a key variable that indicates nutrient availability and loss. EC is related to the plant's physiology, growth, and quality. SenseCAP wireless LoRaWAN 3-in-1 sensor can measure these three factors at the same time to make gardening/farming/agriculture solutions smart and lightweight.
S2105 wireless soil moisture, temperature, and EC sensor is based on FDR technology with advantages of simple, safe, fast, and accurate, long-term measurement, wide range, and simple calibration. It is a kind of soil moisture measurement instrument worth recommending.
Built-in Bluetooth avoids time-consuming configuration works to bring no code experience to individuals with less or no technical background to quickly get started with air temperature and humidity sensing detection.
This sensor can cover a transmission range of 2km in urban scenes and 10km in line of sight scenes while keeping the transmission process low power to support years of usage. Remote monitoring can also benefit large-scale deployment, it gives you the biggest efficiency by saving time and manual labor needed to deploy and manage devices. Together with a replaceable battery that supports Max.10 years of usage and an industrial IP66 enclosure, it meets the need for LoRaWAN-based IoT Solutions in the real world.
We have an article in Learn to introduce the separate network architecture when you choose different LoRaWAN network servers and platforms.
LoRaWAN network coverage is required when using sensors, there are two LoRaWAN network options.
Option 1: Sensors work in areas covered by Helium Network(Check on Helium Explore Map ).
Option 2: Sensors work in a standard LoRaWAN network, like The Things Network, Loriot, Chirpstack, etc.
Tips: The battery is a standard Li-SOCl2 battery (type: ER34615) that can purchase from Amazon and other platforms.
Comparison between SenseCAP S210x and Traditional LoRaWAN Sensors
By preventing plant stress days to improve yields and keep nutrients in the fibrous root zone, the senor enables optimal timing for effective irrigation. It uses metal probes to measure conductivity and soil moisture, demonstrating sensor's high sensitivity and low detection limits.
The EC of the soil temperature and humidity are important conditions that affect the environment in the root zone of greenhouse plantings. The sensor helps gain control over the root zone environment of the greenhouse by making irrigation decisions. If applied properly, it can significantly improve the yield and reduce the cost of greenhouse growing.
The concept of soil moisture monitoring is now being applied to turf management. Salt problems in turfgrass can be difficult to manage since the soluble salts in the soil restrict plant growth. The sensor, used by industry's turf professionals and council turf managers, can achieve actual savings and benefits.
Drought Monitoring
Planting, irrigation, and land management increase soil salinity levels and occur naturally in arid and semi-arid climates. Such droughts can affect the economy and even lead to a regional famine. Thus, the sensor can accurately predict and characterize harmful droughts.
|
Soil Moisture (VWC-Volumetric Water Content) |
|
|
Range |
0 to 100% (air-water) |
|
Accuracy |
0 to 50%: ±3% 50 to 100%: ±5% |
|
Resolution |
0 to 50%: 0.1% 50 to 100%: 0.5% |
|
Soil Temperature |
|
|
Range |
-40 to +80 °C |
|
Accuracy |
0 to 50°C: ±0.5 °C -40 to 0, 50 to 80°C: ±1 °C |
|
Resolution |
0.1 °C |
|
Electrical Conductivity (Only supported in S2105) |
|
|
Range |
0 to 23 dS/m |
|
Accuracy |
0 to 5 dS/m: ±5% 5 to 23 dS/m: ±10% |
|
Resolution |
0 to 5 dS/m: 0.01dS/m 5 to 23 dS/m: 0.1dS/m |
|
General Parameters |
|
|
Product Model |
S2105 |
|
Microcontroller |
Wio-E5 |
|
Support Protocol |
LoRaWAN v1.0.3 Class A |
|
Built-in Bluetooth |
App Tool to change parameters |
|
LoRaWAN Channel Plan |
IN865/EU868/US915/AU915/ AS923/KR920/RU864 * |
|
Max Transmitted Power |
19dBm |
|
Sensitivity |
-136dBm@SF12 BW=125KHz |
|
Communication Distance |
2 to10km (depending on gateway antenna and environments) |
|
IP Rating |
IP66 |
|
Operating Temperature |
-40 to +85 °C |
|
Operating Humidity |
0 to 100 %RH (non-condensing) |
|
Device Weight |
405g |
|
Device Length |
5 meters |
|
Certification |
CE / FCC / RoHS（Testing certification in progress） |
|
Battery (Contained in equipment) |
|
|
Battery Life |
Up to 10 years** |
|
Battery Capacity |
19Ah (non-rechargeable) |
|
Battery Type |
Standard D-size SOCl2 Battery |
The frequency plan setting is none by default and it will not transmit RF signal until it has been set by App via Bluetooth at the first power-up. And it can be changed to other frequency plans at any time.
