Description

Elevate your drone's performance with the XING2 3110 Brushless Motor - a groundbreaking advancement in the world of unmanned aerial technology. Since its inception, the XING series has consistently set benchmarks in the drone motor market, and the XING2 is no exception. It's not just a successor; it's a complete evolution.

Revolutionized Motor Design: The XING2 motor is a testament to superior engineering, marked by our new center slotted N52H curved arc magnets. This innovative feature significantly enhances motor response time, addressing the critical issue of translation delay in braking and acceleration. The result is a motor that offers a faster response, translating your PID loop more quickly and providing that elusive locked-in flight experience.

Optimized for Efficiency and Power: At the heart of the XING2's efficiency are its meticulously crafted components. The minimized magnet air gap and stator lamination, paired with the high-quality materials used, lead to a remarkable increase in magnetic flux. This means not only heightened efficiency but also more power at your fingertips.

Robust Build Quality: Durability meets design in the XING2. The motor boasts a 5mm titanium alloy shaft - our strongest yet. Coupled with the crash-resistant 7075 aluminum bell and the enduring NSK 11x5x5 bearings, this motor is built to withstand the rigors of both casual and competitive flying.

Features At A Glance:

• Ultra-Strong Shaft: 5mm titanium alloy for unparalleled durability.
• Crash Resilience: 7075 aluminum bell designed for impact resistance.
• Long-Lasting Bearings: Smooth, NSK 11x5x5 bearings for prolonged usage.
• Advanced Magnets: Center slotted N52H curved arc magnets for rapid response.
• Protective Design: XING O-ring for bearing gap protection and motor wires protector.
• Balanced Performance: Dynamically balanced for stable operation.
• Versatile Compatibility: Ideal for 7/8/9 inch Cinelifter drones.

Specifications:

• KV Ratings: Available in 900KV, 1250KV, and 1600KV.
• Weight: 77g (including wire).
• Dimensions: φ38.72*24.6mm.
• Interphase Resistance: Ranges from 36mΩ to 73mΩ.
• Input Voltage: Suitable for 33.6V / 25.2V.
• Peak Current: 65.54A / 84.68A / 65.06A.
• Maximum Wattage: Ranges from 1550.4W to 2143.8W.
• Mounting Holes: 19*19 φ3mm.
• Rotor Type: Unibell.
• Shaft Diameter: 5mm with 15mm protrusion.
• Lead: 260mm/18AWG.
• Magnet Type: N52H Curved.
• Configuration: 12N14P.
• Bearing Type: NSK, with φ11 φ5 5 specifications.
• Winding: Single Strand copper winding.

In The Box:

• 1 x XING2 3110 Brushless Motor.
• 4 x M3x10 screws.
• 1 x M5 Flange Nut.

The XING2 3110 Brushless Motor is more than just an upgrade; it's a leap forward in drone motor technology. Its cutting-edge design and superior materials promise to deliver unmatched efficiency, power, and reliability. Whether you're a hobbyist or a professional, the XING2 motor is designed to transform your flying experience. Elevate your drone's capabilities today with the XING2 3110 Brushless Motor.
